aluminium 6061, Gravity Casting Interface, hydroformed, Tapered Head Tube, thru-axle M12 (1.75) x 142mm, disc brake Post Mount
DRIVE UNIT
Bosch Performance CX BDU2..., 250W, 75Nm, 25km/h
DISPLAY
Bosch Intuvia
BATTERY
Bosch PowerPack, 500 Wh
CHARGER
Bosch quick charger 4A
FORK
SR Suntour NCX-E45 LOR Lockout, air, Travel: 60mm, aluminium steerer tube 1 1/8" - 1 1/2" tapered, thru-axle
SHIFTING SYSTEM
Shimano Deore XT M8000 Shadow Plus, 11-speed
GEAR LEVER
Shimano SLX M7000, rapidfire
REAR SPROCKET
Shimano SLX M7000, 11-42 teeth
CHAIN
Sram PC1110
CHAIN RING
Sram X-Sync, 16
BRAKE LEVER
Magura MT4 HC-lever, aluminium
FRONT BRAKE
Magura MT4, 180mm, hydraulic disc brakes
REAR BRAKE
Magura MT4, 160mm, hydraulic disc brakes
TYRES
Schwalbe Super Moto X, 62-584
RIMS
Rodi TR35, with eylets, aluminium
FRONT WHEEL HUB
XLC aluminium disc, thru axle 15x100
REAR WHEEL HUB
XLC Evo disc, thru axle 12x142
SPOKES
Sapim Leader, black
HANDLEBAR
Haibike Components TheBar ++ 740mm
GRIPS
XLC lock on grips Sport
STEM
Haibike Components TheStem ++, A-head, Bar bore: 31.8mm, 6˚
HEAD SET
A-Head Tapered, Cartridge, aluminium
SADDLE
XDURO Light MTB
SADDLE SUPPORT
Haibike Components The Seatpost ++, patent, 31.6mm
PEDALS
XLC Freeride Plattform Pedal
KICK STAND
Ursus Mooi, adjustable
WEIGHT
21.9kg
TOTAL PERM. WEIGHT
130kg
WHEEL SIZE
27.5"
Warranty
The statutory liability for material defects applies to the entire bicycle for two years. Excluded from this are wear and tear parts. You can get more information about the wear and tear parts in your Haibike manual.
