FRAME
aluminium 6061, Gravity Casting Interface, hydroformed, Tapered Head Tube, quick-release 5 x 135mm, disc brake Post Mount -
DRIVE UNIT
Yamaha PW-System, 250W, 25km/h -
DISPLAY
Yamaha LCD -
BATTERY
Yamaha Lithium Ion, 500 Wh -
CHARGER
Yamaha quick charger 4A -
FORK
SR Suntour NCX-EBLO, steel spring/ elastomere, Travel: 63mm, aluminium steerer tube 1 1/8" - 1 1/2" tapered -
SHIFTING SYSTEM
Shimano Deore XT T8000, 20-speed -
FRONT DERAILLEUR
Shimano Deore XT M781 -
GEAR LEVER
Shimano SLX M7000, rapidfire -
REAR SPROCKET
Shimano HG50, 11-36 teeth -
CHAIN
KMC X10e -
CHAIN RING
FSA, 36-48, aluminium -
BRAKE LEVER
Shimano Deore XT M8000, aluminium -
FRONT BRAKE
Shimano Deore XT M8000, 180mm, hydraulic disc brakes -
REAR BRAKE
Shimano Deore XT M8000, 160mm, hydraulic disc brakes -
TYRES
Michelin Protek Cross, 42-622 -
RIMS
Rodi Black Rock Disc, hollow rim, aluminium -
FRONT WHEEL HUB
XLC Evo disc, quick release axle, CL -
REAR WHEEL HUB
XLC Evo disc, quick release, CL -
SPOKES
Sapim Leader, black -
HANDLEBAR
Haibike Components TheBar ++ -
GRIPS
Herrmans Line Ergo lock on grips -
STEM
Haibike Components TheStem +, A-head, Bar bore: 31.8mm, 7˚ -
HEAD SET
A-Head Tapered, Cartridge, aluminium -
SADDLE
Selle Royal Milo -
SADDLE SUPPORT
Haibike Components The Seatpost ++, patent, 31.6mm -
PEDALS
VP 469, non-slip -
HEAD LIGHT
AXA Blueline, 30 lux -
TAILLIGHT
AXA Blueline -
DYNAMO
via system battery -
CARRIER
StandWell system carrier, XLC Carrymore -
MUDGUARD
SKS, chromoplastics -
KICK STAND
Ursus Mooi, adjustable -
WEIGHT
23.2kg -
TOTAL PERM. WEIGHT
130kg -
WHEEL SIZE
28"
The statutory liability for material defects applies to the entire bicycle for two years. Excluded from this are wear and tear parts. You can get more information about the wear and tear parts in your Haibike manual.
